Operation Section
-119-
Lift Fork Adjustment
WARNING
When adjusting the fork spread, be careful not to
pinch your hand between forks and the carriage slot.
Hook - on type Fork
1. Move up the hook pin to the free position.
2. Raise the hook pin in each fork to side the fork on
the carriage bar.
3. Adjust the forks in the position most appropriate for
the load and as wide as possible for load stability.
4. When adjusting the forks, make sure that the weight
of the load is centered on the truck.
5. After adjustment, set the fork locks to keep the forks
in place.
WARNING
Make sure the forks are locked before carrying a
load.
