DIAGNOSTIC TROUBLE CODE (DTC) CHART – SORTED BY DTC # (1 of 4)
Description
DTC Set 2
Description
DTC Set 2
SPN-2 FMI-2 SPN-2 FMI-2
DTC 11: Intake cam / distributor
position error
520800 7
DTC 268: Injector 3 coil shorted
653 6
DTC 16: Crank and/or cam could not
synchronize during start
636 8
DTC 270: Injector 4 open or short to
ground
654 5
DTC 24: Exhaust cam position error
520801 7
DTC 271: Injector 4 coil shorted
654 6
DTC 87 Fuel pressure lower than
expected
94 1
DTC 273: Injector 5 open or short to
ground
655 5
DTC 88 Fuel pressure higher than
expected
94 0
DTC 274: Injector 5 coil shorted
655 6
DTC 91: FP low voltage
94 4
DTC 276: Injector 6 open or short to
ground
656 5
DTC 92: FP high voltage
94 3
DTC 277: Injector 6 coil shorted
656 6
DTC 107: MAP voltage low
106 4
DTC 279: Injector 7 open or short to
ground
657 5
DTC 108: MAP pressure high
106 16
DTC 280: Injector 7 coil shorted
657 6
DTC 111: IAT higher than expected
stage 1
105 15
DTC 282: Injector 8 open or short to
ground
658 5
DTC 112: IAT voltage low
105 4
DTC 283: Injector 8 coil shorted
658 6
DTC 113: IAT voltage high
105 3
DTC 285: Injector 9 open or short to
ground
659 5
DTC 116: ECT higher than expected
stage 1
110 15
DTC 286: Injector 9 coil shorted
659 6
DTC 117: ECT voltage low
110 4
DTC 288: Injector 10 open or short
to ground
660 5
DTC 118: ECT voltage high
110 3
DTC 289: Injector 10 coil shorted
660 6
DTC 121: TPS1-2 lower than expected
51 1
DTC 1631: PWM1-Gauge1 open /
ground short
697 5
DTC 122: TPS1 voltage low
51 4
DTC 299: Boost control underboost
failure
1692 1
DTC 123: TPS1 voltage high
51 3
DTC 301: Cylinder 1
emissions/catalyst damaging misfire
1323 31
DTC 127: IAT higher than expected
stage 2
105 0
DTC 302: Cylinder 2
emissions/catalyst damaging misfire
1324 31
DTC 129: BP pressure low
108 1
DTC 303: Cylinder 3
emissions/catalyst damaging misfire
1325 31
DTC 134: EGO1 open / lazy
724 10
DTC 304: Cylinder 4
emissions/catalyst damaging misfire
1326 31
DTC 140: EGO3 open / lazy
520209 10
DTC 305: Cylinder 5
emissions/catal
y
st dama
g
in
g
misfire
1327 31
DTC 154: EGO2 open / lazy
520208 10
DTC 306: Cylinder 6
emissions/catalyst damaging misfire
1328 31
DTC 160: EGO4 open / lazy
520210 10
DTC 307: Cylinder 7
emissions/catalyst damaging misfire
1329 31
DTC 171: Adaptive-learn gasoline
bank1 high
520200 0
DTC 308: Cylinder 8
emissions/catalyst damaging misfire
1330 31
