Operation Section
88
2) Press this switch and release it after 3 sec, SCR
Cleaning will be started and the engine speed
will be increased. Screen pop-up provides
information on the warning up and cleaning
process.
Warming up process
Cleaning process
Completed
3) The switch returns to the normal position of "2"
after pressed by the operator to position "1".
However, it does not return when pressed to
position "3" and the operator shall return the
switch from position "3".
4) Setting this switch to position "3" prohibits
automatic SCR Cleaning in an environment
subject to dust, explosion or regulated noise
level. At position "3", a pop-up appears as shown
below:
SCR Cleaning inhibited
