Doosan DCT2PS - Using the Tool

Look for these signs on machines shipped to markets in North America, which point out potential hazards to the
safety of you and others. Read and understand thoroughly. Take notice of warnings and follow instructions.
If you do not understand, inform your supervisor.
DANGER CAUTION
Red Background
Indicates the presence of a hazard which WILL cause
serious injury, death or property damage, if ignored.
Yellow Background
Indicates the presence of a hazard which WILL or can cause
injury or property damage, if ignored.
WARNING NOTICE
Orange Background
Indicates the presence of a hazard which CAN cause
serious injury, death or property damage, if ignored.
DCT2PS, DCT3PS and DCT5PS Pickhammers are designed for breaking concrete and other demolition work
in construction applications.
Doosan Benelux SA is not responsible for customer modifications of tools for applications on which Doosan Benelux
SA was not consulted.
The use of other than genuine Doosan replacement parts may result in safety hazards, decreased tool performance, and
increased maintenance, and may invalidate all warranties.
Repairs should be made only by authorised trained personnel. Consult your nearest Doosan Authorised Servicenter.
IMPORTANT SAFETY INFORMATION ENCLOSED.
READ THIS MANUAL BEFORE OPERATING TOOL.
IT IS THE RESPONSIBILITY OF THE EMPLOYER TO PLACE THE INFORMATION
IN THIS MANUAL INTO THE HANDS OF THE OPERATOR.
FAILURE TO OBSERVE THE FOLLOWING WARNINGS COULD RESULT IN INJURY.
Blue Background
Indicates important set-up, operating or maintenance
information.
NOTICE
WARNING
NOTICE
PLACING TOOL IN SERVICE
• Alwaysoperate,inspectandmaintainthistoolin
accordance with all regulations (local, state, federal and
country), that may apply to hand held/hand operated
pneumatic tools.
• Forsafety,topperformance,andmaximumdurability
of parts, operate this tool at 90 psig (6.2 bar/620 kPa)
maximum air pressure at the inlet with 1/2” (13 mm) inside
diameter air supply hose.
• Alwaysturnofftheairsupplyanddisconnecttheair
supply hose before installing, removing or adjusting
any accessory on this tool, or before performing any
maintenance on this tool.
• Donotusedamaged,frayedordeterioratedairhosesand
fittings.
• Besureallhosesandfittingsarethecorrectsizeandare
tightly secured.
• Alwaysuseclean,drylubricatedairat90psig
(6.2 bar/620 kPa) maximum air pressure. Dust, corrosive
fumes and/or excessive moisture can ruin the motor of an
air tool.
• Donotlubricatetoolswithflammableorvolatileliquids
such as kerosene, diesel or jet fuel.
• Donotremoveanylabels.Replaceanydamagedlabels.
USING THE TOOL
• Alwaysweareyeprotectionwhenoperatingorperforming
maintenance on this tool.
• Alwayswearhearingprotectionwhenoperatingthistool.
• Keephands,looseclothingandlonghairawayfrom
rotating end of tool.
• Anticipateandbealertforsuddenchangesinmotion
during start up and operation of any power tool.
• Keepbodystancebalancedandfirm.
Do not overreach when operating this tool.
• Toolaccessoriesmaycontinuetoimpactbrieflyafter
throttle is released.
• Airpoweredtoolscanvibrateinuse.Vibration,repetitive
motions or uncomfortable positions may be harmful to
your hands and arms. Stop using any tool if discomfort,
tingling feeling or pain occurs.
Seek medical advice before resuming use.
• UseaccessoriesrecommendedbyDoosan.
• Thistoolisnotdesignedforworkinginexplosive
atmospheres.
• Thistoolisnotinsulatedagainstelectricshock.
16
EN
