Doosan DCT2PS - Tool Specification

SPECIFICATIONS FOR DCT2PS, DCT3PS AND DCT5PS PICKHAMMERS
Model Chuck Size Cpn Overall Overall Weight Max Air
Length Width Kg (lbs) Working Consumption
mm (in) mm (in) Pressure M
3
/min @ 6
Bar (psi) Bar (CFM)
DCT2PS 15R/12 hex x55 93482990 300 (12) 60 (2.4) 2.6 (5.7) 6.2 (90) 0.35 (12.5)
DCT3PS 19 hex x50 01338060 335 (13.2) 60 (2.4) 3.5 (7.7) 6.2 (90) 0.35 (12.5)
DCT5PS 19 hex x50 01337674 408 (16.6) 60 (2.4) 5.0 (11.0) 6.2 (90) 0.43 (15.0)
77
Model Certified Certified Impact Handle Air inlet Air
Vibration Noise Frequency /Cylinder Connector Connection
Level M/s
2
Level L
WA
/min Torque Torque
@ 6 bar Nm (lbs.ft) Nm (lbs.ft)
DCT2PS 3.1 105 2850 50 (37) 12 (9) 3/8“ BSPP Female thread
DCT3PS 9 105 3850 50 (37) 12 (9) 1/2“ BSPP Male thread
DCT5PS 7 105 2650 50 (37) 12 (9) 1/2“ BSPP Male thread
TOOL SPECIFICATION
