DCT3PS CPN DCT5PS CPN (PART NO. (PART NO. FOR FOR ORDERING) ORDERING) Grip Handle Assembly........................................................................... PH3–50111 03764206 PH5–50202 03764396 1 Grip Handle .................................................................................... PH3–50110 03764214 PH5–50201 03764404 1A Safety Throttle Lever ...................................................................... PH3–50130 93483279 PH5–50130 56746654 1B Safety Lever ................................................................................... PH3–50131 93483287 PH5–50131 56746662 1C Safety Lever Pin ............................................................................. PH3–50132 93483295 PH5–50132 56750573 1D Safety Lever Spring ........................................................................ PH3–50133 93483303 PH5–50133 56748080 2 Throttle Lever ........................................................................................ PH3–50101 03764222 PH3–50101 03764222 • 3 ThrottleLeverPin .................................................................................. PH3–50102 03764230 PH3–50102 03764230 5 Throttle Valve Stem Bushing ................................................................. PH3–50104 03764248 PH3–50104 03764248 • 6 ThrottleValveStem ............................................................................... PH3–50105 03764263 PH3–50105 03764263 • 7 ThrottleValveFace ............................................................................... PH3–50106 03764271 PH3–50106 03764271 • 8 ThrottleValvePin .................................................................................. PH3–50107 03764289 PH3–50107 03764289 • 9 ThrottleValveSpring ............................................................................. PH3–50108 03764297 PH3–50108 03764297 10 Inlet Bushing Assembly ......................................................................... PH3–50127 03768835 PH3–50127 03768835 • 10A InletBushingSeal .......................................................................... PH3–50128 03768843 PH3–50128 03768843 • 11 O–ring.................................................................................................... PH3–50112 03764313 PH5–50203 03764503 • 12 CylinderSpacer 1 mm thick ............................................................................................. – – PH5–50204 03764511 2 mm thick ............................................................................................. – – PH5–50223 03768868 3.6 mm thick .......................................................................................... PH3–50126 03768850 – – 13 Washer Guide ....................................................................................... PH3–50115 03764347 – – 14 Upper Valve Seat .................................................................................. – – PH5–50205 03764529 15 Spring Washer Assembly (set of 3 Washers) ....................................... PH3–50116 03764354 – – 16 Piston Bumper ....................................................................................... – – PH5–50209 03764560 17 Piston Shield ......................................................................................... PH3–50117 – – – • 18 Valve ...................................................................................................... – – PH5–50206 03764537 19 Lower Valve Seat .................................................................................. – – PH5–50207 03764545 • 20 ValvePin(2) .......................................................................................... – – PH5–50208 03764552 21 Piston .................................................................................................... PH3–50118 03764370 PH5–50210 03764578 22 Cylinder ................................................................................................. PH3–50113 03764321 PH5–50211 03764586 23 Nozzle ................................................................................................... – – PH5–50212 03764594 24 Retainer ................................................................................................. PH3–50114 03764339 PH3–50114 03764339 25 Handle locking screw ............................................................................ PH3–50537 85043065 PH3–50537 85043065 * Nameplate ............................................................................................. – 22112999 – 22113005 * Tune–up Kit (includes illustrated parts 3, 6, 7, 8, 9, 10A and 11) ......... PH3–TK1 – – – (includes illustrated parts 3, 6, 7, 8, 9, 10A, 11, 12, 18 and 20 [2]) ...... – – PH5–TK1 – * Silencer ................................................................................................. PH5–50222 18034736 PH5–50222 18034736 • IndicatesTune–upKitpart. * Not illustrated.
75
