OP000756
4-13
Inspection, Maintenance and Adjustment
The number is also stamped in the rear frame on the left side
just below the cabin (Figure 10).
Engine Serial Number
The engine name plate (identification label) is attached to
engine headcover (1, Figure 11). The engine serial number is
stamped on the right rear of the engine block, under exhaust
manifold (2, Figure 11).
Safety Precautions
1. Before performing any maintenance checks, move pilot
cutoff switch to "LOCKED" position. Place a Warning Tag
on controls so that no one begins to operate machine while
maintenance checks are being performed.
2. Clean up all fuel spills. Fuel spills are hazardous,
especially around engine.
3. Inspect all fuel lines for leakage. Replace any lines, fittings,
O-rings, or filters that show signs of wear or damage.
4. If a test procedure requires engine to be running, use two
people and keep all unnecessary personnel away from
machine.
FG008058
Figure 10
FG006234
1
2
Figure 11
