11. Electric system
171
Starter
General Information
The starter is attached to the back of the flywheel housing.
When disassembling the engine, immerse the pinion gear
and ring gear of the starter in fuel, brush them, and then
apply greases to them in order to prevent rust.
Specification
• Starter should be protected from humidity all the
time.
• Before working on the electric system, be sure to
disconnect the ground wire("-" minus wire) of the
battery. Short circuit may occur while working on
the electrical system. Connect the ground wire last
after completing all of work.
Specification
NOMINAL OUTPUT 24V, 7.0kW
ENGAGEMENT SYSTEM AUXILIARY ROTATION SYSTEM/SOFT START
Max. RATED TIME 30 SEC
ROTATION CLOCKWISE VIEWED FROM THE PINION
SWITCH HOLD-IN CURRENT
MAGNETIC SWITCH 2.3A
SOLENOID SWITCH 15A
