G424F(FE) Service Manual Chapter 5. Engine Management System (EMS) 126
Service Standard
Basic Idle rpm (After warm up) No Load 750±15 rpm
Ignition Timing (After warm up, at idle) BTDC 5°±5°
Tightening Torques
Items
N∙m kgf∙m 1bf∙ft
Heated Oxygen Sensor (HO2S, Sensor 1) 50 ~ 60 50 ~ 60 36. 2 ~ 43.4
Heated Oxygen Sensor (HO2S, Sensor 2) 50 ~ 60 5.0 ~ 6.0 36.2 ~ 43.4
Crankshaft Position Sensor (CKPS) 6 0.6 4.3
Camshaft Position Sensor (CMPS) 4 ~ 6 0.4 ~ 0.6 2.9 ~ 4.3
Engine Coolant Temperature Sensor (ECTS) 15 ~ 20 1.5 ~ 2.0 10.8 ~ 14.5
Delivery pipe installation 22 ~ 28 2.2 ~ 2.8 15.7 ~ 20.3
