Care and maintenance
CLEANING INSTRUCTIONS FOR BUCKLE
1
1b
1a
1c
Follow the manufacturer’s instructions at all times.
Before removal, ensure you have carefully noted the
way which the various parts are attached to the seat so
as to facilitate reassembly.
Your child car seat is equipped with a buckle designed
to give your child maximum protection during proper
use (Figure 1). When working properly, your buckle
should always fasten with an audible ‘CLICK’.
If sticky liquids (such as baby food, fruit juice, etc.) get
into the buckle it may become sluggish and you will not
hear a ‘CLICK’.
REMOVING BUCKLE:
1. Lay seat on back to allow easy access for buckle
removal (Figure 1a).
2. Using a at object (such as a at-head screw-driver,
not included) gently slide the Metal Plate (Figure
1b) into a loosened position, repeat on
the other side.
3. Turn each metal plate and push through the top
opening to release crotch buckle for cleaning
(Figure 1c).
