6
English
Follow Illustrations Fig 4.1 - 4.4 below.
To hold the door open
1) Open the door to the required position. (Fig 4.1)
2) Stand sideways to the door. (Fig 4.2)
3) Press the black knob down using your foot. Greater foot pressure may be needed
depending upon the force from the door closer or the type of floor surface.
4) While depressing the black knob, pull the door gently in the direction of closing. (Fig 4.3)
5) Remove your foot and let go of the door.
To release Dorgard
a) Lightly kick the black knob toward the door. (Fig 4.4)
b) Push the door in the direction of opening.
Note: If the door has been pushed hard against the floorplate bump stop or a wall, then Dorgard
will only release by method a).
Figure 4.1 Figure 4.2
Operating Dorgard
Fit&OpGuideINTERNATIONAL 23/7/04 2:20 pm Page 8
