Dorgard DG1328-FP - Beep and LED Messages Explained

English
Beep and LED Messages Explained
Beep / Flash Sequence What it means What to do
During Power up
LoHi-LoHi-LoHi Indicates battery lift is open No action required
during power up
Long Tone Indicates start of power up test No action required
Lo – Lo – Lo No dip switch has been selected No action required
Hi – Lo – Lo Dip switch 1 has been selected No action required
Lo – Hi – Lo Dip switch 2 has been selected No action required
Hi – Hi – Lo Dip switches 1 and 2 No action required
have been selected
Lo – Lo – Hi Dip switch 3 has been selected No action required
Hi – Lo – Hi Dip switches 1 and 3 No action required
have been selected
Lo – Hi – Hi Dip switches 2 and 3 No action required
have been selected
Hi – Hi – Hi Dip switches 1, 2 and 3 No action required
have been selected
Dip switch 4 has no function and
will not affect beep sequence
During standard operation
*----(32secs)----*----(32secs)----*----(32secs)----*----etc. LED indicates that the system is No action required
working properly
*-(1.3secs)-*-(1.3secs)-*-(1.3secs)-*-(1.3secs)-*-etc LED indicates that the Dorgard If no alarm is sounding
is hearing a possible alarm (or a please refer to the
continuous background noise section on adjusting
in excess of 65dB) the sensitivity of
Dorgard.
HiLo – HiLo – HiLo – HiLo – HiLo – HiLo – HiLo – HiLo Dorgard is about to release door No action required
*--------*--------*--------*--------*--------*--------*--------* (If warning tone has been
disabled – then no tone will sound)
* LED flash
10
During normal operation Dorgard is continually monitoring all functions. If at any time it detects
a possible fault or maintenance issue it will Fail to Safe (no longer operate as a hold open device).
It will emit a series of beeps to communicate action is required. The following Beep and LED
Messages Explained chart should be used to identify error and action required. Please follow
these instructions. Should your problems persist please see contact details on back cover.
