Beep Sounds During Auxiliary Relay Default: No
Selects whether or not the keypad beeps during Auxiliary Relay
activation.
Press: 4 2 # Sound #
Sound=1 for Yes, =0 for No
Beep Sounds During Output #3 Default: No
Selects whether or not the keypad beeps during Output #3
activation.
Press: 4 3 # Sound #
Sound=1 for Yes, =0 for No
Beep Sounds During Output #4 Default: No
Selects whether or not the keypad beeps during Output #4
activation.
Press: 4 4 # Sound #
Sound=1 for Yes, =0 for No
Keypad Lockout Count Default: 3 Tries
Sets the number or incorrect entry code attempts allowed
before the keypad “locks out”.
Press: 5 0 # Attempts #
Attempts=Number of attempts before lockout (2-7)
Anti-Pass Back Time Default: No Anti-Pass Back
Sets the length of time an entry code will not function after it is
used.
Press: 5 1 # Minutes #
Minutes=Time in minutes (1-4), 0=No Anti-passback
RESETTING KEYPAD
Master Reset
CAUTION: Performing a master reset will clear the
entire memory of the AC-228 and return all
programmable options to the factory default values.
ALL ENTRY CODES WILL BE ERASED.
STEP 1 Disconnect power from the keypad.
STEP 2 Press and hold down the * and # keys.
STEP 3 Apply power to the keypad, continue holding the keys
down until the red indicator starts flashing
STEP 4 Release the keys. The red and yellow indicators will
remain lit until the process is complete, then the
yellow indicator will go out.
Resetting the Master Code
STEP 1 Open the AC-228 case.
STEP 2 Locate jumper at P2. This jumper is used to reset the
master code.
STEP 3 With power applied to the keypad, remove the jumper
at P2. The keypad will begin to beep, signaling that
the code has been reset.
STEP 4 Replace jumper on P2
THE MASTER PROGRAMMING CODE IS NOW 123456.
Beep Sounds During Main Relay Default: 2 Seconds
Selects whether or not the keypad beeps during Main Relay
activation.
Press: 4 1 # Sound #
Sound=1 for Yes, =0 for No
Solid-state Output #4 On-time Default: 2 Seconds
Sets the length of time Output #4 activates when triggered.
Press: 2 4 # Seconds #
Seconds=Output time in seconds (0-60), 99=Toggle Mode
Beep Sounds on Keystrokes Default: 2 Seconds
Selects whether or not the keypad beeps as each key is pressed.
Press: 4 0 # Sound #
Sound=1 for Yes, =0 for No
Page 7
08279830 Rev.01/07 Page 7 of 8
