Dormakaba SafeRoute STL-G Series User Manual

11STL-G/STL-G NT 2020-07WN 059727-45532
dormakaba Mounting instructions Mounting
4.2 Assignment of terminals and switch/button
STV1xx
STV5xx
TV-Z 510
STV2xx
SCU-TL
X2
X3
X4
1
A
B3
Out2
1G
In1
3
1
Out1
AS
GND
Rx
Tx
RS232
18 k
J-Y(St)Y 2x2x0,8
STV xxx
1
A
B
3
DCW
®
ST
X5
X2
X3
X4
1
A
B3
Out2
1G
In1
3
1
Out1
AS
GND
Rx
Tx
DCW
®
X1
X5
S2
S4
S6
S
B
ON
1 2
LED SLI
S5
A
B
X1
X1
Connection to key switch ST
X2
A
1
3
B
1G
Out2
24VDC
DCW® bus
DCW® bus
GND
24VDC
Output 2
Stabilized power supply
Switched voltage (test “Power Reserve Modul M-SVP/SVP”)
Common alarm (default value)
X3
3
In1
1
Out1
AS
5–28VDC
GND
18k
Output 1
Static control (default value)
Output
Locked (default value) Alarm system, e.g. fire alarm system or smoke
detector (see default value)
X4
Rx
Tx
3
GND
TxD
RxD
RS232 interface
X5
Connection to distributor STL-G-S
LED SLI LED display license card/application card
S2
BS
Service switch for suppression of tamper alarm:
B = Operation (housing tampering contact activated)
S = Service (housing tampering contact shut off, internal and external
tampering messages are suppressed)
S4 Service button
S5
AB
Alarm system switch
A = alarm system activated
B = alarm system not connected (default value)
S6
DIP switch for setting the number of doors (operation of SCU-TL with
license card and multi-door application) or to set up the DCW® address
of other connected emergency buttons (operation of SCU-TL without
license card):
DCW® address DIP switch
1
2
3
4
0
1
0
1
0
0
1
1
Number of doors DIP switch
1
2
3
4
0
1
0
1
0
0
1
1
