Dormakaba SafeRoute STL-G Series User Manual

63
86
300
A
95
63
86
300
A
95
4
STL-G/STL-G NT
2020-07
WN 059727-45532
dormakaba Mounting instructions Mounting
1A 1B
2A
1.
2.
3.
1.
1.
1.
1.
230V
NYM 3 x 1.5 mm²
J-Y(St)Y 2x2x0.8
(DCW® bus)
J-Y(St)Y 2x2x0.8
(DCW® bus)
STL-G
STL-G STL-G NT
4 Mounting
WARNING
Risk to life due to electric shock.
Works on electrical systems must only be
carried out by qualified electricians.
• Before starting work on electrical systems
and equipment, establish a voltage-
free state and maintain this state while
carrying out the work.
4.1 Mount the door terminal
