Dormakaba SafeRoute STL-G Series User Manual

dormakaba Deutschland GmbH
DORMA Platz 1 58256 Ennepetal Germany T: +49 2333 793-0 F: +49 2333 793-4950 www.dormakaba.com
4.3 Complete mounting
1. Document the mounting and commissioning in
the inspection log.
2. Hand over this document to the facility operator.
5 Disassembly, recycling and
disposal
Disassembly is carried out in the reverse order of
mounting and must be carried out by qualified
personnel.
The product must be disposed of in an
environmentally friendly manner.
Electrotechnical parts and batteries must not
be disposed of as domestic waste. Dispose of
electrotechnical parts and batteries in the designated
acceptance and collection points. Refer to the
statutory regulations for your country.
Translation of the original manual, subject to change without notice
STV1xx
STV5xx
TV-Z 510
STV2xx
SCU-TL
X2
X3
X4
1
A
B3
Out2
1G
In1
3
1
Out1
AS
GND
Rx
Tx
RS232
18 k
J-Y(St)Y 2x2x0,8
STV xxx
1
A
B
3
DCW
®
ST
X5
X2
X3
X4
1
A
B3
Out2
1G
In1
3
1
Out1
AS
GND
Rx
Tx
DCW
®
X1
X5
S2
S4
S6
S
B
ON
1 2
LED SLI
S5
A
B
X1
STL-G-S *
Example of wiring diagrams
STL-G NT + STVxxx
Optional
alarm system
Power
supply unit
NT
*for louder acoustic signals
and the housing’s tamper contact
