2 Saflok Quantum Pixel PK3693_T 02-19
©
2018 dormakaba USA, Inc. All trademarks and registered trademarks are the property of their respective owners.
Saflok Quantum Pixel Installation Instructions
IMPORTANT
All parts needed to install the Quantum Pixel lock are included with each unit. Please check to make sure
all parts are accounted for before you begin the installation. Do not substitute any of the parts. The use
of substitute parts will result in poor performance of the lock.
All information contained herein, including but not limited to product pricing and other intellectual
property, is confidential and intended for the sole use of the addressee(s) so named. Any misuse of this
confidential information contained herein may result in legal action by dormakaba USA Inc. and
its parent company.
Door and door frame preparation
Tools required for this step
Recommend doors prepped at factory for higher precision
Do not drill both STD and ADB Ø7/16 thumb turn holes. Drill only the hole that corresponds to the mortise
purchased. Do not drill a Ø7/16 thumb turn hole for utility locks.
• Drill
• Plunge Router
- 1” Straight
- 1-⁄” Straight
• Drill bits
- ⁄” Reader
- ⁄” Thumb Turn
- ⁄” Mortise Mounting
• 2-⁄" Hole Saw
• Chisel
• Jigsaw
• 1:1 Door Prep Templates
• Optional Door Prep Jig P/N: FIXT-PIXEL (available for purchase)
- Door prep jig only available for 1-3/8" [34.9mm] OR 1-3/4" [44.5mm] doors with standard centered
lower mortise pocket and no rabbet.
