(b) Model 12-A(B) panel mount specifications.
(c) Model 20-A(B) or Model 21-A(B) panel mount specifications. Model 21-
A(B) is a vertical panel mount meter.
(a) Model 10-A(B) panel mount specifications.
Fig. 5. Physical specifications for several panel mount models.
4.250 "
MODEL 10-A(B) OPENING
5.000 "
(METER CLEARANCE BEHIND PANEL)
CUSTOMER'S PANEL
8.562 "
MODEL 12-A(B) OPENING
CUSTOMER'S PANEL
(single console or panel mount meter)
(dual console or panel mount meter)
MODEL 20-A(B) OR 21-A(B) OPENING
(console or panel mount meter-straight lined LED's)
7.900 "
CUSTOMER'S PANEL
8.750 "
(METER CLEARANCE BEHIND PANEL)
8.560 "
(METER CLEARANCE BEHIND PANEL)
2.00 " 2.50 "
(METER CLEARANCE
BEHIND PANEL)
2.00 " 2.50 "
(METER CLEARANCE
BEHIND PANEL)
1.30 "
1.75 "
(METER CLEARANCE
BEHIND PANEL)
(5.5 " maximum depth)
(5.5 " maximum depth)
(5.5 " maximum depth)
