DOSKO 620-20HE - Brake Lever & Air Cleaner Installation

Assembly Instructions
37
4. Mount adjustable
brake lever
Align bolt holes in the adjustable brake lever with the holes in the mounting posts
on the stump grinder handle bar and install bolts with nuts.
(Image 3)
5. Install air cleaner
assembly (620 only)
Align air cleaner mount with bolt holes and install bolts as shown. Then, remove
the tape from the intake on engine.
Intake on
engine
Air Cleaner
Mount
