INSTALLATION DRAWINGS:
Fig 1
Current installation
is approx
10
1
2
"
266
installed as shown in Fig 1.
Advantage 40 should be currently
Disconnect Advantage 40
Remove 1.5" Union and 194900
as shown in Fig 2.
194900
1.5" Union
Remove
SuperDos 45.
Fig 2
Remove
the extra width of the
194900
Remove
Cut line to accommodate
Remove
1.5" Union
The following pages show the necessary steps to convert your set up from our Advantage injectors to the new
SuperDos.
