134 Specifications and requirements
1
The 4U56 enclosure uses 3.5" LFF disks. Remove the enclosure bezel and open the drawer to view disk drive module LEDs.
2
The 2U48 enclosure uses 2.5" SFF disks. Remove the enclosure bezel and open the drawer to view disk drive module LEDs.
3
The 2U24 enclosure uses 2.5" SFF disks. Remove the enclosure bezel to view disk drive module LEDs.
4
The 2U12 enclosure uses 3.5" LFF disks. Remove the enclosure bezel to view disk drive module LEDs.
Figure 109 Rackmount enclosure dimensions
..
ABCDEFGH
Form cm in cm in cm in cm in cm in cm in cm in cm in
4U56
1
45.1 17.8 17.8 7.0 47.9 18.9 2.5 .98 78.2 30.8 3.0 1. 2 83.3 32.8 90.9 35.8
2U48
2
44.7 17.6 8.9 3.5 47.9 18.9 2.5 .98
72.4 28.5 3.0 1. 2 74. 4 29.3 81.5 32.1
2U24
3
47.6 18 .7 3.0 1. 2 51. 8 20.4 57.9 22.8
2U12
4
52.7 20.5 3.0 1. 2 54.9 21.6 59.9 23.6
Table 46 Rackmount controller enclosure weights
Specifications Rackmount
SFF controller enclosure (2U24)
• Chassis with FRUs (no disks)
1-3
• Chassis with FRUs (including disks)
1- 4
8.6 kg (19.0 lb) [chassis]
17.4 kg (38.4 lb)
23 . 4 k g ( 51. 6 l b )
LFF controller enclosure (2U12)
• Chassis with FRUs (no disks)
1-3
• Chassis with FRUs (including disks)
1- 4
9.3 kg (20.6 lb) [chassis]
18 .1 kg (4 0 .0 l b )
27.7 kg (61.0 lb)
A
C
BE
DF
G
H
1
2
3
4
5
Key for generic enclosure diagram:
−
Front view without disks (section removed)
2
−
Enclosure top view (section removed)
3
−
Enclosure side view (section removed)
4
−
Enclosure bezel top view (reference only)
5
−
Enclosure bezel side view (reference only)
Critical−fit dimensions (see table)
A−H:
Note: For clarity, only key view projection lines are shown.
45° orthographic bisector
