DOTECH FX3DH - Wiring; Main Wiring Diagram; Option Module Connection; Sensor Connection Guide

- 2 -
R20160613
35
78
70
28
8
UNIT : mm
90
40
(Panel Cut-Out : 71mm X 29mm)
Dimensions and Panel Cut-Out Form
Wiring
L2L1
100-240Vac,
50/60Hz
1 2 3 4 5 6 7 8 9 10 11
COM
OUT1 OUT2
+5VNTC
FX3DH
OPTION
MODULE
c
Vin
5A, 250Vac
POWER
SUPPLY
Humidity
TEMP
R
W(Y)
B
%
COM +5VNTC Vin
8 9 10 11
YELLOWBLUE WHITE
BLACK
RED
HTX20-FTS-502
Temp. & Humidity sensor
COM +5VNTC Vin
8 9 10 11
YELLOWBLACK RED
HTX20-FTS-502
Humidity sensor
COM +5VNTC Vin
8 9 10 11
WHITEBLACK RED
HTX3515
Humidity sensor
8 9 10 11
COM +5VNTC Vin
NTC
DPR-TH01-ET
Temp. sensor
※ Set sensor input setting(
IN
)
of setting 2 group to
HT
.
※ Set sensor input setting(
IN
)
of setting 2 group to
H
.
※ Set sensor input setting(
IN
)
of setting 2 group to
H
.
※ Set sensor input setting(
IN
)
of setting 2 group to
T
.
1
2
3
4
4~20mA
4~20mA
SG
RED
WHITE
BLACK
-A1 Model
4~20mA Output
1
2
3
4
TRX
TRX
SG
RED
WHITE
BLACK
-R4 Model
RS485 COMM.
1
2
3
4
TRX
TRX RED
BLUE
WHITE
BLACK4~20mA
4~20mA
-A1R4 Model
4~20mA Output
& RS485 COMM.
Sensor connection
Option Module connection
NO Connection Description
1
POWER 100-240Vac, 50/60Hz
2
3
OUT1
Relay output OUT1 when closed
4 Common signal
5
OUT2
Relay output OUT2 when closed
6 Common signal
7 Relay output OUT2 when open
8 NTC Temp. sensor input
9 COM Common signal
10 Vin Humidity sensor input
11 +5V Humidity sensor power (5Vdc)
Accessories
HTX20-FTS-502
DOTECH INC.
RH : 10~95%RH, 1.2~3.5V
T : NTC5K
RH & Temp Sensor
+5
V
RH
GND
TH
TH
63
63
48
Red : Humidity sensor power +5V
Yellow : Humidity measurement signal output
Black : Humidity sensor power 0V
white : Temperature sensor(NTC5K)
Blue : Temperature sensor(NTC5K)
Cable length
3M
Humidity range: 10 ~ 95%RH
Temp. range: 0 ~ 60℃
Humidity output :1.2~3.5V
Temp. output: NTC5K
27 25
12
2.5pie
6.7
Humidity range: 0~100%RH
Humidity output: 1.0~3.6Vdc
Connection Cable length 3M
1: Black : Humidity sensor power 0V
2: Red : Humidity sensor power+5V
4: White : Humidity measurement
signal output
Ø5
35
SUS PIPE SHRINK TUBE LEAD WIRE
HTX20-FTS-502
DOTECH INC.
RH : 10~95%RH, 1.2~3.5V
T : NTC5K
RH & Temp Sensor
+5
V
RH
GND
TH
TH
63
63 48
Red : Humidity sensor power +5V
Yellow : Humidity measurement signal output
Black : Humidity sensor power 0V
white : Temperature sensor(NTC5K)
Blue : Temperature sensor(NTC5K)
Cable length
3M
Humidity range: 10 ~ 95%RH
Temp. range: 0 ~ 60℃
Humidity output :1.2~3.5V
Temp. output: NTC5K
27 25
12
2.5pie
6.7
Humidity range: 0~100%RH
Humidity output: 1.0~3.6Vdc
Connection Cable length 3M
1: Black : Humidity sensor power 0V
2: Red : Humidity sensor power+5V
4: White : Humidity measurement
signal output
Ø5
35
SUS PIPE SHRINK TUBE LEAD WIRE
HTX20-FTS-502 : Temp.& Humidity sensor HTX3515 : Humidity sensor
DPR-TH01-ET : Temperature sensor
