WIL-12350-E-02 23 WILDEN PUMP & ENGINEERING, LLC
EXPLODED VIEW & PARTS LISTING
*See Elastomer Chart - Section 9.
1
Air Valve Assembly includes item numbers 2, 3, 4, and 5.
2
Power Piston Seal Kit includes item numbers 21, 22, 23, and 24.
3
Bushing Assembly, Center Section, includes qty. 1 of item numbers 34 and 4.
4
Stand Assembly includes item numbers 58 and 59.
Product contact components.
All boldface items are primary wear parts.
Item Part Description Qty.
H1500/SZSII/…
P/N
H1500/SSSII/…
P/N
AIR DISTRIBUTION COMPONENTS
1 Air Valve Assembly
1
1 08-2003-45 08-2003-45
2 End Cap w/Guide Nylon 1 08-2306-23 08-2306-23
3 End Cap w/o Guide Nylon 1 08-2336-23 08-2336-23
4 O-Ring (-220) (Ø1.359 x Ø.139) 2 15-2390-52 15-2390-52
5 Retaining Ring 2 15-2650-03 15-2650-03
6 Screw, SHC, Air Valve (5/16”-18 x 2 3/4”) 4 08-6000-03-83 08-6000-03-83
7 Air Valve Gasket 1 08-2601-52 08-2601-52
8 Screw, SHC, Manifold (3/8”-16 x 1 1/2”) 2 99-6034-08 99-6034-08
9 Nipple, 1” NPT, Galvanized 1 08-7430-08-60 08-7430-08-60
10 Elbow, 90°, 1” NPT, Galvanized 1 08-7840-08-60 08-7840-08-60
11 Muer 1 15-3510-99 15-3510-99
12 Manifold, Bottom Air Valve 1 08-2700-45 08-2700-45
13 Plate, Isolator Cover 1 08-2705-45 08-2705-45
14 Gasket, Air Valve Isolator 1 08-2603-52 08-2603-52
15
Relief Tube Assembly
2 08-9232-99-60 08-9232-99-60
16 Pressure Relief Valve Assembly 2 08-2742-99-60 08-2742-99-60
Rebuild Pressure Relief Seal Kit 1 99-9346-99 99-9346-99
17 Pipe 2 08-7520-03-60 08-7520-03-60
18 Pipe 2 08-7510-03-60 08-7510-03-60
19
O-Ring (-114) Pipe (Ø.612 x Ø.103)
8 00-2870-52 00-2870-52
20
Power Piston Seal Kit
2
1 08-9210-99-60 08-9210-99-60
21 O-Ring (-379) Cover (Ø10.975 x Ø.210) 2 - -
22 Guide Ring, Bronze-Fille
d
2 - -
23 Slipper Seal, PTFE-Filled 1 - -
24
O-Ring (-450) Piston (Ø10.475 x Ø.275)
1 - -
25 Piston, Cylinder 1 08-3720-01-60 08-3720-01-60
26 Bushing, Cylinder Piston 2 08-3730-03-60 08-3730-03-60
27 Shaft 2 08-3800-03-60 08-3800-03-60
28 Stud, Shaft 1 08-6150-08-60 08-6150-08-60
29 Cover, Center Section 2 08-3000-45-60 08-3000-45-60
30 Gasket, Center Section 2 08-3260-52-60 08-3260-52-60
31 Screw, HHC (7/16”-14 x 1”) 24 08-6260-08-60 08-6260-08-60
32 Washer (7/16”) 24 08-6830-03-60 08-6830-03-60
33 Pipe Plug, 1/16” NPT 2 08-7030-08-60 08-7030-08-60
34 Bushing, Assembly Center Section
3
2 08-3300-99-60 08-3300-99-60
35 Glyd Ring 4 15-3210-55-225 15-3210-55-225
O-Ring (-220) (Ø1.359 x Ø.139) Item No. 4
2 15-2390-52 15-2390-52
36 Chamber, Air 2 08-3653-03-60 08-3653-03-60
37 Section, Center 1 08-3158-45-60 08-3158-45-60
38 Washer (1/2”) 12 08-6840-03-60 08-6840-03-60
39 Screw, HHC (1/2”-13 x 1”) 12 08-6132-08 08-6132-08
Item Part Description Qty.
H1500/SZSII/…
P/N
H1500/SSSII/…
P/N
WETTED PATH COMPONENTS
40 Chamber, Liquid CIP 3” EHEDG 2 15-5012-10-385P 15-5012-10-385P
41 Clamp Band Assy, 4” 8 15-7203-03 15-7203-03
42 Elbow, 3” EHEDG 4 15-5240-10-385P 15-5240-10-385P
43 T-Section, 3” EHEDG 2 15-5190-10-385P 15-5190-10-385P
44 Clamp Band, Assy, 3” 4 15-7103-03 15-7103-03
45 Hex Nut, (1/2”-13) 28 15-6420-03 15-6420-03
46 Screw, HHC (1/2”-13 x 1 3/4”) 28 08-6190-08-60 08-6190-08-60
38 Washer (1/2”) 56 08-6840-03-60 08-6840-03-60
GASKETS / VALVE BALLS / MUSHROOM VALVE
47 Gasket, 3”, PKG 4 1 * *
48 Gasket, 4”, PKG 2 4 * *
49 Valve Ball, PKG 4 1 * *
50 Mushroom Valve, PKG 4 1 15-1096-55E 15-1096-55E
CHECK VALVE COMPONENTS
51 Ball Cage, 3” EHEDG 4 15-5350-10-385P 15-5350-10-385P
52 Mushroom Valve Housing 4 15-5431-10-385P 15-5431-10-385P
FSIPD COMPONENTS
53 Piston. Inner, (Non-PTFE) 2 08-3700-03 N/A
55
Diaphragm, Full Stroke IPD, Primary, PKG 2
1 08-1031-57E N/A
TPE COMPONENTS
53 Piston. Inner, (Non-PTFE) 2 N/A 08-3700-03
55 Diaphragm, Primary, PKG 2 1 N/A 08-1011-57E
56 Piston, Outer, (Non-PTFE) 2 N/A 08-4550-10-385P
PTFE COMPONENTS
53 Piston. Inner, (Non-PTFE) 2 N/A 08-3700-03
54
Diaphragm, Full Stroke PTFE, Back-up, PKG 2
1 N/A 08-1065-57E
55
Diaphragm, Full Stroke PTFE, Primary
, PKG 2
1 N/A 08-1040-55E
56 Piston, Outer, (Non-PTFE) 2 N/A 08-4550-10-385P
FIXED STAND COMPONENTS
57 Stand, Pump, PV Assy.
4
1 15-7653-10-385 15-7653-10-385
58 Nut, Cap, 5/16”-18, Pump Stand 4 08-6600-03-72 08-6600-03-72
59 Pad, Pump Stand 4 08-7670-20 08-7670-20
60 Washer, Flat (Ø.390 X Ø.625 X .063) 4 02-6730-03 02-6730-03
61 Screw, HHC, 3/8”-16 X 7/8” 4 08-6140-03 08-6140-03
LW0126 Rev. B
H1500 SANIFLO
TM
HS
1935/2004/EC PARTS LISTING
