Dover Advanced Series User Manual

WILDEN PUMP & ENGINEERING, LLC 24 WIL-12350-E-02
ELASTOMER OPTIONS
Section 9
H1500 SANIFLO™ HS 1935/2004/EC
MATERIAL
DIAPHRAGMS
(Color Code)
FULL-STROKE
BACK-UP DIAPHRAGMS
(Color Code)
VALVE BALL
(Color Code)
GASKET, 3”
(Color Code)
GASKET, 4”
(Color Code)
FDA EPDM N/A N/A N/A 15-1375-74E (green dot) 15-1215-74E (green dot)
FULL-STROKE PTFE 08-1011-55E (white) N/A 15-1086-55E (white) 15-1375-55E (white) 15-1215-55E (white)
FDA WIL-FLEX™ 08-1011-57E (2 orange dots) 08-1067-57E (2 orange dots) 15-1086-57E (2 orange dots) N/A N/A
FDA VITON® N/A N/A N/A 15-1375-68E (white/yellow) 15-1215-68E (white/yellow)
LW0126 Rev. B
H1500 SANIFLO™ HS
MATERIAL
DIAPHRAGMS
(Color Code)
FULL-STROKE
DIAPHRAGMS
(Color Code)
BACK-UP
DIAPHRAGMS
FULL-STROKE
(Color Code)
FULL-STROKE
IPD
DIAPHRAGMS
(Color Code)
VALVE BALL
(Color Code)
GASKET, 3”
(Color Code)
GASKET, 4”
(Color Code)
FDA EPDM N/A N/A N/A N/A N/A
15-1375-74
(green dot)
15-1215-74
(green dot)
PTFE N/A 08-1011-55 (white) N/A N/A 15-1086-55 (white) 15-1375-55 (white) 15-1215-55 (white)
FDA WIL-FLEX™
08-1011-57
(2 orange dots)
N/A
08-1067-57
(2 orange dots)
08-1032-57
(2 orange dots)
15-1086-57
(2 orange dots)
N/A N/A
FDA VITON® N/A N/A N/A N/A N/A
15-1375-68
(white/yellow)
15-1215-68
(white/yellow)
LW0167 Rev. B
