CPS-B1 CPS-B1
99.828.32 1.4/07/2199.828.32 1.4/07/21
4/24 5/24
Power supply
Rated power
Stand-by operating
195 ... 253 V AC, 50 Hz
140 VA
< 2 W
195 ... 253 V AC, 50 Hz
145 VA
< 2 W
24 V DC
<0,5 Vpp; < 1%, load-dependent
Monitoring:
Output current
Mode of operation
Alarm / Ventilation:
Output current
Mode of operation
2,5 A
Short-time duty, 30% ED
5 A
Short-time duty, 30% ED
Number of lines / groups*
Fire detectors per line
SHEV buttons per line
1/1
max. 8 pcs.
max. 8 pcs.
Temperature range
Ingress protection
Protection class
-5 ... +40°C
IP 30
II, with fuctional ground
Housing:
Material
Colour
Dimensions WxHxD
Plastic
white
310 x 310 x 104 mm
* D+H Highspeed (HS) drives will be supported.
Intended use
- SHEV control panel in particular for staircases
- Microprocessor based control panel
- 1 line, 1 group
- 2,5 A or 5 A actuating current
- Comfort functions for daily ventilation
- Only for inside mounting
WARNING
Read all safety warnings, instructions, illustrations
and specifications provided with this product.
Failure to follow all instructions listed below may
result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future
reference.
Operating voltage 230 V AC!
Risk of injury from electric shock!
- Connection has to be carried out only by an
authorized electrical specialist
- Only for inside mounting
- Just use unchanged original D+H parts
Safety notes
An overdue maintenance of the system will be
indicated by the control panel after about ca. 14 to
16 months.
The yellow LED in the smoke vent button will start
flashing.
A malfunction of the smoke vent system will be still
indicated by the extinction of the green LED in the
smoke vent button.
After the maintenance time is expired (approx. 14
to 16 months), the ventilation function OPEN can
be interrupted depending on the presetting of the
service timer.
Attention: Reset of the service timer can be
carried out by a specialist company only, who
has been authorized by the appliance
manufacturer.
Servicetimer
Observe regulations for danger warning systems
VDE 0833, guidelines for electrical systems VdS
2221, VDE 0100, DIN 18232 for smoke and heat
vent systems, regulations of the local fire-brigade
and of EVU for connection to mains supply.
Important regulations
Smoke gases are to be carried off as unhindered
as possible through smoke and heat vent opening
in case of fire. Size, kind and arrangement of the
opening is of decisive significance for an optimal
effect of the smoke and heat vent system.
These requirements are defined in the relevant
regulations of the respective country.
More informations, are also available under
www.rwa-heute.de.
The SHEV opening should be coordinated with the
responsible fire protection authority.
SHEV opening
Declaration of Conformity
We declare under our sole responsibility that the
product described under “Technical Data” is in
conformity with the following directives:
2014/30/EU, 2014/35/EU, 2011/65/EU
Technical file at:
D+H Mechatronic AG, D-22949 Ammersbek
Dirk Dingfelder Maik Schmees
Member of the Board Authorized signatory, Technical Director
05.05.2021
Technical data
English English
High-speed function (HS):
All D+H drives with SHEV high-speed function are
supported. In daily ventilation operation, a consi-
derable noise reduction is achieved through the
reduced drive speed. In case of SHEV the drives
run with a very high speed to reach the OPEN
position defined within 60 seconds at the most.
SHEV retriggering:
(When DIP switch S1.5 = ON)
The smoke vents will be triggered with an OPEN-
impulse every 2 minutes for a duration of 30
minutes. For this, the drives must be blockage
safe. All D+H drives meet this precondition.
Mounting of the drives:
Please take mounting informations from the
relevant instruction for use of the respective drive,
because of varied possibilities for choosing drives.
Notes on drives
To Next Page
