DR
®
TRIMMER/MOWER
™
Assembly & Operating Instructions34
Parts List
Please refer to the schematic drawings on pages 36-37.
Ref # Part # Description
1 116891 Main Frame Orange, PRO
Model
1 139531 Main Frame Black, Comm.
Model
2 145531 Cast Bearing Housing Assembly
2H 145541 Head Assembly Complete
3 143641 Upper Handlebar, Comm. Model
3 144071 Upper Handlebar, PRO Model
4 143631 Lower Handlebar, Comm. Model
4 144061 Lower Handlebar, PRO Model
5 125141 Wheel Retaining Ring & Set
Screw
6 144101 Mow-Ball
™
Support, Nylon
6a 121131 Aluminum Mow-Ball
™
Support
8 114261 Axle
9 123951 Clevis, 3/16" x 1/2"
10 114031 Brake Actuator
11 114111 Idler Arm
12 115121 Brake Assembly
13 114681 Clutch/Brake Control
14 144571 Throttle Control with Cable, PRO
Model
14 144591 Throttle Control with Cable,
Comm. Model
15 114681 Hex Head Bolt, 1/4"-20 x 1-1/4"
16 143661 Handlebar Knob
18 139861 Wheel 16", Comm. Model
18 121321 Wheel 16" Resin, PRO Model
20 143691 Bail bar
21 119621 Brake Rod
22 143541 Backup Plate
23 116801 Rubber Stone Guard
24 131031 Stone Guard Clamp
25 120891 Idler Return Spring
26 118221 PTA Lever
27 143571 Line Spacer Plate
28 120521 Shield Assembly with Brackets
29 144081 Line Plate Stand-Off
Ref # Part # Description
30 121101 Axle Pivot Stud
31 144541 Carriage Bolt, 5/16" – 18 x 3"
32 120641 Bushing, 1/4"
33 117491 PTA Lever Vinyl Grip
34A 114251 PTA Latch Bracket Assembly
35 115001 Latch Bracket Only
36 118941 PTA Pin
36A 125341 PTA Pin, Spring, Clip Assembly
37 120901 PTA Spring
38 119591 PTA Snap Ring/Clip
39 118811 Wear Strip
40 115831 24 Heavy-Duty Cords (pre-cut)
41 115871 Roll of Heavy-Duty Cord
42 115811 24 Extra Heavy-Duty Cords (pre-
cut)
43 115861 Roll of Extra Heavy-Duty Cord
44 121661 Nylon Washer .180 thick
45 120771 Extension Spring, 2" x .52
46 121521 Plastic Axle Washer, .01"
47 118161 Key, 3/16" Square
48 121691 Flat Washer, 5/16"
49 144551 Bolt, HHCS, Gr. 5, 3/8"-16 x 3-
1/4"
50 125371 Engine Pulley with Set Screw
51 120171 Set Screw, 5/16"-18 x 5/16"
52 125381 Head Pulley
53 118691 Hex Nut, 5/16"
54 118731 Nylon Lock Nut 10-24
55 114621 Hex Head Bolt, 1/4"-20 x 2-1/2"
56 121701 Flat Washer, 3/8", SAE
57 112391 Flat Washer, 3/8" USS, for
Engine Pulley
58 120161 Set Screw 1/4"-20 x 3/8" Sq
Head
59 121551 Brake Pivot Washer
60 114431 V-Belt 1/2" x 45", 4L450
61 120101 Hex Head Screw, 10-24 x 5/8"
62 118641 Elastic Stop Nut, 1/4"-20
