DR
®
TRIMMER/MOWER
™
Assembly & Operating Instructions 1
Trimmer Parts & Components
The following parts and assembly components should be in your DR
®
TRIMMER/MOWER
™
package. Please check your shipping box(es) and parts package(s) for the items listed below. If
your shipment is incomplete or if you have any questions, please call us TOLL-FREE
1(800)DR-OWNER(376-9637).
Assembly Components:
1—Upper Handlebar [#143641], Commercial Model, or
[#144071], PRO Model
1—Lower Handlebar [#143631], Commercial Model, or
[#144061], PRO Model
2—Handlebar Adjuster Assemblies [#145801] in separate plastic bag
1—Axle [#114261]
1—Rubber Stone Guard [#116801]
1—PTA
™
Lever [#118221]
1—Acrylic Shield Assembly [#120521]
2—Wheels [#139861], Commercial Model, or
[#121761], PRO Model
Parts Bag Contents:
2—Wheel Retainer Rings [#119551]
2—Stone Guard Clamps [#131031]
1—Black Nylon Axle Washer [#121521]
4—5/16" Washers [#121691]
5—Lock Nuts 5/16"-18 (larger size) [#110761]
2—Set Screws 1/4"-20 Square Head [#120161]
7—Slotted Hex Head Bolts 10-24 x 5/8" Long [#114781]
7—Lock Nuts 10-24 (smaller size) [#118731]
2—U-Bolts [#114851]
1—PTA
™
Lever Grip [#117491]
Please refer to Figure 1 on the next page when preparing to assemble your DR
®
TRIMMER/
MOWER
™
. We recommend laying the parts out in sets, as we have shown them, before
assembly.
