DR 16.5 - Page 48

48 DR
®
SELF-FEEDING CHIPPER
Parts List – Base and Wheels Assembly – Road Tow
Note: Part numbers listed are available through DR Power Equipment.
Ref# Part# Description
1 37423 Base, (16.5)
37424 Base, (21.0)
2 37467 Bracket, Axle
3 37468 Bracket, Fender, (16.5)
37469 Bracket, Fender, (21.0)
4 37762 Bracket, Fender, RH, (16.5)
37469 Bracket, Fender, (21.0)
5 15449 Bolt, HCS, 3/8-16 x 1-1/4, Gr5
6 15448 Nut, Nylon Lock, 3/8-16
7 24259 Fender Weldment
8 11152 Bolt, HCS, 3/8-16 x 1, Gr5
9 15599 Light, Stop, Road Side
10 17814 Light, Stop, Curb Side
11 16679 Bolt, HCS, 5/16-18 x 3/4
12 14313 Nut, Nylon Lock, 5/16-18
13 37465 Axle Weldment, Road Tow
14 24260 Wheel & Tire Assembly, w/Hub
15 37463 Bracket, Tow Bar, Rear
Ref# Part# Description
16 12960 Bolt, HCS, 3/8-16 x 3, Gr5
17 37466 Tow Bar, Road Tow
18 37441 Bracket, Tow Bar, Front
19 16101 Hitch, Trailer
20 14241 Bolt, HCS, 1/2-13 x 3, Gr5
21 24209 Nut, Nylon Lock, 1/2-13
22 14891 Chain, Safety, Class 1
23 15389 Bolt, HCS, 3/8-16 x 3-1/2, Gr5
24 14516 Washer, Flat, 3/8
25 37464 Leg, Support, Road Tow
26 37502 Clevis Pin w/Ring
27 18258 Pin, Cotter, 1/8"
Not Shown
24180 Label, Danger, Read Manual
24261 Label, Danger, 45 mph
24185 Label, Warning, Do Not Climb
14905 Wire Harness, 10ft
