17
PARTS LIST C182-CHP CHIPPER
ITEM # QTY. PART # DESCRIPTION
1 1 913-0023 DEFLECTOR
2 1 913-0215 CHIPPER BASIC MACHINE
3 1 030-0231 18HP BRIGGS & STRATTON ENGINE
4 1 913-0049 FRAME WELDMENT
5 2 911-0219 HITCH ARMS
6 1 911-0220 HITCH TUBE WELDMENT
7 1 911-0035 STAND
8 2 408-0078 SAFETY CHAIN
9 1 913-0218 TRAILER HITCH
10 1 911-0070 AXLE WELDMENT
11 2 911-0210 AXLE BRACKET WELDMENT
12 4 911-0229 3/8-16 X 3” U-BOLT
13 2 911-0025 FENDER WELDMENT
14 2 702-0040 TIRES
15 1 913-0124 BATTERY BOX
16 1 913-0086 BATTERY
17 1 913-0217 BATTERY HOLD DOWN
18 1 030-0211 PULLEY
19 1 030-0237 BUSHING
20 1 911-0236 CLUTCH
21 2 030-0193 5H680 BELT
22 2 911-0221 HITCH ARM MOUNTING PLATES
23 1 913-0056 BELT GUARD “L” MOUNTING BRACKET
24 1 913-0058 BELT GUARD “Z” MOUNTING BRACKET
25 1 911-0214 BELT GUARD “L” MOUNTING BRACKET
26 1 911-0240 INNER BELT GUARD
27 1 911-0248 BELT GUARD WELDMENT
28 1 030-0232 GAS TANK
29 1 913-0053 GAS TANK MOUNTING BRACKET
30 1 913-0054 ENGINE/BELT TIGHTENER
31 1 030-0239 HOSE AND CLAMP ASSEMBLY
33 1 913-0203 BATTERY SPACER
34 1 030-0266 ROAD SIDE STOP LIGHT
35 2 913-0206 TAIL LIGHT MOUNTING BRACKET
36 1 500-0039 3/16” HAIR SPRING COTTER
37 4 090-0162 10-32 X 3/8” SELF TAPPING SCREW
38 1 911-0249 SPACER
39 1 704-0106 WASHER
40 4 090-0128 ½-13 X 1 ¼” HHCS
41 4 090-0370 ½-13 X 3” HHCS
42 4 090-0050 ½-13 GRIPCO LOCKNUT
43 2 703-0424 ¼ X ¼ X 2” KEY
44 18 090-0088 5/16-18 X 1” HHCS
45 3 090-0394 5/16 SPLIT LOCKWASHER
46 11 090-0233 5/16 USS FLATWASHER
47 3 090-0438 5/16-18 J-NUT
49 15 090-0461 3/8-16 NYLOCK NUT
50 4 090-0066 5/16-18 X 1 ¾” HHCS
51 17 090-0460 5/16-18 NYLOCK NUT
52 3 090-0234 3/8 USS FLATWASHER
53 1 090-0123 3/8-16 X 3 ½” HHCS
55 1 090-0422 3/8-24 X 1 ½” HHCS
56 4 090-0111 3/8-16 X 1 ¼” HHCS
57 4 090-0453 ¼-20 WHIZ NUT
58 2 090-0077 5/16-18 X 4” HHCS
--- 1 030-0265 CURB SIDE STOP LIGHT
--- 1 913-0059 POSITIVE BATTERY CABLE
--- 1 911-0228 NEGATIVE BATTERY CABLE
--- 1 030-0267 WIRE HARNESS
