PARTS LIST – 913-0215 CHIPPER BASIC MACHINE
Item No. Qty. Part No. Description
1 1 913-0034 DRIVE SIDE PLATE WELDMENT
2 9 090-0048 5/16-18 GRIPCO NUT
3 1 911-0163 CHIPPER DISC WELDMENT
4 1 030-0118 FLYWHEEL TAPERLOCK
5 1 500-0031 ¼ X ¼ X 1” KEY
6 1 913-0022 FLYWHEEL SHAFT
7 1 913-0042 SCROLL WELDMENT
8 2 911-0010 KNIFE
9 6 090-0642 5/16-18 X 1 ½” SOCKET HEAD CAP SCREW
10 2 913-0021 SCROLL TUBE
11 3 090-0257 ¼-20 X 1” SOCKET FLAT HEAD SCREW
12 1 911-0055 WEAR PLATE
13 10 090-0460 5/16-18 NYLOCK NUT
14 8 090-0233 5/16 USS FLATWASHER
15 1 911-0164 CHIPPER HOPPER
16 4 090-0462 5/16-18 X ¾’ CARRIAGE BOLT
17 9 090-0077 5/16-18 X 4” HHCS
18 3 090-0245 ¼ SAE FLATWASHER
19 4 090-0111 3/8-16 X 1 ¼” HHCS
20 3 090-0470 ¼-20 NYLOCK NUT
21 4 090-0042 3/8-16 GRIPCO NUT
22 2 030-0115 SHAFT BEARING
23 8 090-0162 10-32 X 3/8 SELF TAPPING SCREW
24 1 913-0035 CHIPPER SIDE PLATE WELDMENT
25 2 090-0024 SHIM
26 2 030-0117 RETAINING RING
27 2 913-0210 ACCESS COVER
CHECK OIL LEVEL
BEFORE STARTING CHIPPER
