32 DR
®
SELF-FEEDING WOOD CHIPPER
Chapter 6: Parts List and Schematic Diagrams
Parts List - Chipper Basic Assembly
Note: Part numbers listed are available through DR Power Equipment.
Ref# Part# Description
1 10000023310 Flywheel, Balanced, W/Knife
2 10000043433 Sideplate, Hopper
3 10000043406 Scroll
4 10000043434 Discharge Weldment
5 10000043461 Sideplate, Vent
6 110761 Nut, Nylon Lock, 5/16-18
7 10000043452 Plate, Access, 3 Hole
8 276441 Bearing, 2 Bolt, 1 in
9 10000043505 Ring, Retaining 1" Shaft
10 10000043463 Scroll Tube
11 380481 Knife Kit
12 10000045612 Bolt, Low Head 3/8-16 X 1
13 10000043470 Plate, Wear
14 157471 Bolt, Carriage, 1/4-20 X 1˝
Ref# Part# Description
15 112381 Washer, Flat, 1/4" , SAE
16 222131 Bolt, 5/16-18 X 3-5/8 GR5 ZP
17 110731 Nut, Nylon Lock, 1/4-20
18 10000043472 Plate, Access, 2 Hole
19 10000045476 Spacer, 1.015" ID X 1.50" X .062"
20 164131 Nut, Nylon Lock, 3/8-16, LP
Not Shown
10000042639 Label, Warning
10000042667 Label, Danger
10000042683 Label, Warning Rotating Blade
10000037322 Decal, Prop 65
197091 Gauge, Knife Gap
