44 DR
®
SELF-FEEDING WOOD CHIPPER
Parts List Base and Wheels Assembly Yard Tow
Note: Part numbers listed are available through DR Power Equipment.
Ref# Part# Description
1 10000043417 Base, Weldment (Pro)
10000043476 Base, Weldment (Pro-XL)
2 10000033736 Axle (Pro)
10000033679 Axle (Pro-XL)
3 10000046608 Bearing, Flange, Axle
4 111521 Bolt, HCS, 3/8-16 x 1, Gr5
5 110751 Nut, Nylon Lock, 3/8-16
6 10000033833 Spacer, Wheel
7 110731 Nut, Nylon Lock, 1/4-20
8 10000043571 Support, Axle
9 10000043534 Wheel & Tire, 4.10 3.50-6
10 10000045531 Collar, Locking, 3/4" Shaft
Ref# Part# Description
11 10000043513 Tow Bar, Yard Tow
12 10000043477 Hitch Plate, Bent
13 111581 Bolt, 5/16-18 x 1", HCS Gr5 PLTD
14 110761 Nut, Nylon Lock, 5/16-18
15 10000043479 Leg, Support, Yard Tow
16 129601 Bolt, HCS, 3/8-16 X 3", Gr5, PLTD
17 323971 Pin, Clevis 3/8 In X 2-3/4 in With
Ring ZP (Pro)
18 10000045533 U Bolt
19 10000043494 Bracket, Tow Bar, Front
20 10000043522 Bracket, Tow Bar, Rear
