46 DR
®
SELF-FEEDING WOOD CHIPPER
Parts List – Base and Wheels Assembly – Road Tow
Note: Part numbers listed are available through DR Power Equipment.
Ref# Part# Description
1 10000043417 Base, Weldment (Pro)
10000043476 Base, Weldment (Pro-XL)
2 10000043514 Bracket, Axle
3 10000043502 Bracket, Fender Road Side (Pro)
10000043523 Bracket, Fender (Pro-XL)
4 10000043515 Bracket, Fender, Curb Side (Pro)
10000043523 Bracket, Fender (Pro-XL)
5 150431 Bolt, HCS, 3/8-16 x 1-1/4, Gr5
6 110751 Nut, Nylon Lock, 3/8-16
7 10000043516 Fender, Weldment
8 111521 Bolt, HCS, 3/8-16 x 1, Gr5
9 10000043870 Light, Stop, Road Side
10 10000043818 Light, Stop, Curb Side
11 123211 Bolt, HCS, 5/16-18 x 3/4
12 110761 Nut, Nylon Lock, 5/16-18
13 10000043532 Axle Weldment, Road Tow
14 252971 Wheel & Tire Assembly
15 10000043540 Bracket, Tow Bar Rear
Ref# Part# Description
16 129601 Bolt, HCS, 3/8-16 x 3, Gr5
17 10000043541 Tow Bar, Road Tow
18 10000043494 Bracket, Tow Bar, Front
19 161011 Hitch, Trailer
20 354711 Bolt, HCS, 1/2-13 x 3, Gr5
21 110721 Nut, Nylon Lock, 1/2-13
22 10000043785 Chain, Safety, Class 1
23 354621 Bolt, HCS, 3/8-16 x 3-1/2, Gr5
24 112391 Washer, Flat, 3/8
25 10000043447 Leg, Support, Road Tow
26 323971 Pin, Clevis 3/8 in X 2-3/4 in with
Ring ZP
27 253181 Cap, Dust
28 10000041630 Bracket, Light Support
29 253101 Nut, Castle 1-14 ZP
30 253111 Pin, Cotter 5/32 X 2 ZP
Not Shown
10000043343 Label, Warning Tow Max 45mph
10000046523 Wire Harness, Road Tow
