DR Pro 475 - Hopper Assembly Parts and Schematic

48 DR
®
SELF-FEEDING WOOD CHIPPER
Parts List – Hopper Assembly
Note: Part numbers listed are available through DR Power Equipment.
Ref# Part# Description
1 10000043419 Hopper Neck, (Pro)
10000043486 Hopper Neck, (Pro-XL)
2 10000043439 Hopper, Top, (Pro)
10000043491 Hopper, Top, (Pro-XL)
3 10000043490 Hopper, Bottom, (Pro)
10000043454 Hopper, Bottom, (Pro-XL)
4 10000043482 Hopper, Side, LH, (Pro)
10000043483 Hopper, Side, LH, (Pro-XL)
5 10000043484 Hopper, Side, RH, (Pro)
10000043456 Hopper, Side, RH, (Pro-XL)
6 10000043838 Screw, BHCS 5/16-18 X 3/4 GR5 ZP
Ref# Part# Description
7 10000043872 Screw, BHCS 5/16-18 X 1/2 GR5 ZP
8 187551 Nut, Nylon Lock, 5/16-18, LP
9 10000043562 Shield, Blow Back (Pro)
10000043499 Shield, Blow Back (Pro-XL)
10 10000043504 Support, Blow Back (Pro)
10000043553 Support, Blow Back (Pro-XL)
11 157301 Bolt, HCS, 1/4-20 x 3/4", GR5
12 112381 Washer, Flat, 1/4", SAE
13 110731 Nut, Nylon Lock, 1/4-20
14 112411 Washer, Flat, 5/16"
