DR PRO MAX 60T - Page 12

12 DR
®
TOW-BEHIND FIELD AND BRUSH MOWER
4. Gently spread open the cable clamps and install them onto the Remote Control
Cable, positioning the clamps on the tow bar. Keep the Control Cable flat and
centered on the Tow Bar (Figure 17).
Cable Routed
over Push Bar
Tow Bar
Cable
Clamp
s
Figure 17
Remote
Control Cable
