DR PRO MAX 60T - Page 6

6 DR
®
TOW-BEHIND FIELD AND BRUSH MOWER
Chapter 2: Assembling the DR TOW-BEHIND FIELD and BRUSH MOWER
Item
Part
Description
Qty
Figure
1
365721
BOLT - HEX - FLANGE - 1/2-13 X 3.5 - GR5
8
2
187571
BOLT-HCS 5/16-18 X 3.75
2
3
385991
BOLT-HEX FLANGE 5/16-18 X 1.75 GR5
4
4
385981
BOLT-HEX FLANGE 5/16-18 X 2.5 GR8
4
5
362891
BUSHING - SWAY BRACE
8
6
157201
KEY-IGNITION SWITCH
2
7
333351
NUT-NYLON LOCK FLANGED 1/2-13
8
8
333321
NUT-NYLON LOCK FLANGED 5/16-18
10
9
235001
PIN - COTTER 7/64 X 1.0 ZP
2
10
255491
PIN CLEVIS - 1/2 X 2.5 in TRT
3
11
A0000253563
PIN CLEVIS 1/2 X 4.5 in L ZP
1
12
397351
PIN-ACTUATOR-40 mm
2
13
160031
PIN-HITCH CLIP 1/2-9/16
4
14
111701
SCREW - 10-32 X 0.5 TYPE F
2
15
234991
WASHER - 0.53 ID X 1.06 OD X 0.095 - ZP
4
16
112411
WASHER-FLAT 5/16 USS
2
17
123211
BOLT-HCS 5/16-18 X 0.75 GR5 ZP
2
18
110761
NUT-LOCK NYLON 5/16-18
2
Compare the hardware of the Product Package with the “Parts Supplied” list above. If there are any questions, please contact us at
www.DRPower.com.
