28 DR
®
WIDE-CUT LAWN MOWER
Chapter 6: Parts Lists and Schematic Diagrams
Parts List – Deck Assembly
Note: Part numbers listed are available through DR Power Equipment.
Ref# Part# Description
1 362801 Spindle Assembly, Finish
2 395701 Blade, 15.13", High Lift
3 395561 Pulley, 3.5" OD, 3/4" Hub, A Profile
4 395521 Bushing, Idler, Blade Belt
5 395511 Arm, Idler, Blade Belt
6 396141 Cover, Belt, 30" Deck
7 A0000043848 Spring, Ext, 1" OD X 3"L X 0.105
Wire
8 10000047518 Guide, Belt, Sheet metal, Blade
Pulley, 3.5"
9 10000040695 Pulley, Blade Brake, 3.5"
10 395341 Wheel, Front, 8" X 2", Square Tread
11 395361 Axle, Front
12 395391 Bushing, Axle
13 10000040701 Guard, Side Discharge
14 10000041169 Spring, Torsion, Discharge Guard
15 10000040677 Bracket, Discharge Cover
16 A0005906464 Deck, Cast, Pro MAX30 w/labels
17 395621 Belt, A40, Wrapped
18 10000040960 Rod, Pivot, -Side Discharge Guard
19 10000040720 Deflector, Discharge
Ref# Part# Description
20 144091 Pulley, V-Belt, 2-5/8"
21 395611 Chute, Discharge
22 396281 Plug, Mulching
23 379151 Bushing, Belt Guide
24 352811 Bolt, Hex Flange, TL, 3/8-16 X 3/4"
25 289901 Screw, Unsltd Trilobe, 3/8-16 X 1"
26 111731 Screw, 5/16-18 X 1/2", Tri
27 101451 Bolt, HSC, 1/4-20 X 1-1/2", GR5, ZP
28 114561 Bolt, HCS, 1/4-20 X 2", GR5, ZP
29 119851 Bolt, HCS, 3/8-16 X 1 1/2", GR5, ZP
30 333331 Nut, Nylon Lock, Flanged, 3/8-16
31 333351 Nut, Nylon Lock, Flanged, 1/2-13
32 333311 Nut, Nylon Lock, Flanged, 1/4-20
33 365631 Bolt, Hex Flange, 1/2-13 X 1.25",
GR8, ZP
34 A0005536864 Label, Deck
35 362791 Cap, Spindle, Finish
36 371691 Key, ANSI #605 Woodruff, 3/16" X
5/8"
37 136491 Label, Danger
38 A0000277001 Guard, Rear Deck, 30", Right
A0000276999 Guard, Rear Deck, 30", Left
39 A0000222874 Nut, Nylon Lock, 1/4-20 Thin, ZP
40 112381 Washer, Flat, 1/4 USS
Not Shown:
A0000247447 Label, Warning, Only Replace with
DR Belts
