DR PRO-XL 44T User Manual

30 DR
®
TOW-BEHIND FIELD and BRUSH MOWER
Parts List – Deck Assembly
Note: Part numbers listed are available through DR Power Equipment.
Ref# Part# Description
1 363121 Rod, Acme Thread, Height Adjust
2 365741 Shim, Nylon, 0.76″ Id X 0.1.31″ OD X
0.06″ THK
3 365761 Knob, 4-Lobe, 5/16-18 X 1/2″ Stud
4 354991 Block, Height Adjust
5 362541 Crank, Hand
6 371211 Crank, Hand, Break-away
7 354881 Deck, Brush, 44″
8 391051 Rail Support, 3/8″ Strips
9 354921 Channel, Support, Left
10 354931 Channel, Support, Right
11 362551 Cover, Belt
12 362591 Spindle Assembly
13 362611 Cap, Spindle
14 322371 Key, ANSI 806 Woodruff, 1/4″ X 3/4″
15 365461 Blade Carrier
16 354831 Blade, Swinging, Air Tip
17 363071 Washer, Blade
18 373821 Arm, Idler
19 362581 Bushing, 0.380″ X 0.664″ X 0.9″
20 362561 Pulley, 11″ OD - 1″ Bore, 1/4″ Key B
21 151271 Pulley, Flat Idler, 4″
22 365551 Spring, 1″ OD - 8″ L, 0.105″ Wire
23 365641 Bolt, Hex, Flange, 3/4-10 X 1.75″, GR8
ZP
24 365631 Bolt, Hex, Flange, 1/2-13 X 1.25″,GR8
ZP
Ref# Part# Description
25 352811 Bolt, Hex, Flange, TL, 3/8-16 X 3/4″
26 10000032164 Bolt, HH Tap Blt W/ Loctite Patch,
3/8-16 X 2-1/4″, GR5 ZP
27 114651 Bolt, HCS FT, 3/8-16 X 3″, GR5 ZP
28 111481 Bolt, 1/4-20 X 1 3/4″, GR5 ZP
29 112391 Washer, Flat, 3/8″, USS
30 222531 Washer, Split, 3/8″, GR8, ZP
31 333381 Nut, Nylon Lock, Flanged, 3/4-10
32 365751 Nut, Hex, Acme Thread, 1/2-10, GR2
33 333331 Nut-Nylon Lock Flanged 3/8-16
34 187551 Nut, Nylon Lock, 5/16-18, LP
35 110731 Nut, Nylon Lock, 1/4-20
36 365771 Pin, Detent, Grip Ring, 1/4″ X 1-1/4″,
ZP
37 323411 Collar, Shaft, Clamp-On, 1/2″
38 136491 Label, Danger
39 371191 Mount, Molex (Pro & Pro XL)
40 363111 Clamp, Cable, 3/4″ Nylon (Pro & Pro
XL)
41 373401 Clamp, Cable, 3/8″, Nylon Black (Pro
& Pro XL)
42 111701 Screw, 10-32 X 1/2″, Type F (Pro &
Pro XL)
43 371221 Label, Warning
44 391091 Rail Support, 3/8″ Strips, w/Labels
Not Shown
A0000176962 Label, Premier 44T (Premier)
A0000174595 Label-Pro 44T (Pro)
A0000176944 Label-Pro XL44T (Pro XL)
