34 DR
®
PRO XL520 CHIPPER SHREDDER
Chapter 6: Parts Lists and Schematic Diagrams
Parts List – Shredder Assembly
Note: Part numbers listed are available through DR Power Equipment.
Ref# Part# Description
1 10000041629 Spacer-Hammer
2 10000041665 Hammer-Serrated
3 10000042639 Label-Warning Chipper/Trimmer
4 10000041619 Rotor
5 A0004945685 Shaft- Hammer CS3 Pro Xl
6 A0000176951 Sideplate-Chipper Side
7 A0000176940 Sideplate-Drive Side
8 A0000176950 Housing-Upper Scroll
9 10000041648 Housing-Fin Scroll
10 10000041646 Guard-Chute-Chipper
11 A0000176945 Plate-Knife Access
12 A0005097260 Plate-Hammer Access
13 A0000176947 Housing-Top Plate
14 10000041647 Guard-Discharge 21.0 CS3
15 10000041678 Plate-Wear
16 A0000176948 Hopper-Shredder 21.0 CS3
17 A0000176934 Chute-Chipper 21.0 CS3
18 10000043547 Bearing-Flange-1-1/4" Shaft
19 10000041711 Screen 21.0 CS3
20 A0000058030 Trim-U Channel-.125 Vinyl
21 10000041973 Bushing-QD-1.25-SDS
22 10000041916 Pulley-Vbelt-2 Groove-7.15" OD
23 10000041724 Bracket-Belt Guard-Sideplate Mount
24 A0000258771 Guard-Belt Rear
25 110731 Nut-Lock Nylon 1/4-20
26 26 110751 Nut-Lock Nylon 3/8-16
Ref# Part# Description
27 110721 Nut-Nylon Lock 1/2-13
28 111521 Bolt-HCS 3/8-16 X 1 Gr5 Zp
29 112381 Washer-Flat 1/4" Uss
30 112391 Washer-Flat 3/8" Uss
31 164521 Key-Square 1/4" X 2" In
32 165131 Bolt-Hex 3/8-24x1 1/4 Gr8 W/Patch
33 157301 Bolt-HCS 1/4-20 X 3/4 GR5 ZP
34 228871 Washer–385 ID 1.5 OD .25L
35 321041 Bolt-Carriage-3/8-16 X 1-GR5 ZP
36 333321 Nut-Nylon Lock Flanged 5/16-18
37 386541 Bolt-Carr 1/2-13 X 1-1/2 Gr5 Zp
38 A0000075292 Bolt-HHCS-.375-16 X 11 Gr5 Zp
39 A0000175161 Label-CS3 PRP XL502
40 A0000181455 Label-DR Logo-5.5 IN
41 386691 Label-Screen Bolt
42 10000042667 Label-Danger-Chipper/Trimmer
43 10000042683 Label-Warning Rotating Blade
44 A0000222999 Label-Operating CS3 PROXL
45 A0005092914 Nut-Flange Distorted Thread 3/8-24
46 A0005260804 Bracket-Shredder Hopper-XL502
47 A0005165373 Support-Shredder Hopper-XL502
48 A0005165371 Guard-Shredder Hopper-XL502
49 380491 Knife Kit
