Chapter 2: Setting Up the DR PRO XL520 CHIPPER-SHREDDER
It may be helpful to familiarize yourself with the controls and features of your DR PRO XL520 CHIPPER-SHREDDER as shown in
Figure 2 before beginning these procedures. If you have any questions at all, please feel free to contact us at www.DRpower.com.
PRO XL520 CHIPPER-SHREDDER Controls and Features
Figure 2
Pneumatic Tires
Chipper Hopper
Shredder Hopper
DR 12.0 HP , 420cc E/S Engine
Leg-Support
Blowback Shield
Blowback Shield
Fuel Tank
Battery
Fuel Tank Cap
Discharge
Access Door for
Chipper Knife
Check
Belt Guard
Hitch
Plate
Wear Plate
Tow Bar
Starter Cord
Throttle
Fuel
Shut Off
Choke
Control
Lever
Ignition
Switch
