DR XD30 User Manual

32 DR
®
FIELD and BRUSH MOWER
Chapter 6: Parts Lists and Schematic Diagrams
Parts List - Handlebar Assembly
Note: Part numbers listed are available through DR Power Equipment.
Ref# Part# Description
1 333321 Nut, Nylon Lock, Flanged, 5/16-18
2 333331 Nut, Nylon Lock, Flanged, 3/8-16
3 333311 Nut, Nylon Lock, Flanged, 1/4-20
4 A0001293097 Nut, Finish, 5/16-24, ZP
5 A0000646660 Link, Traction Control, Lower
6 333501 Bolt, Hex, Flange, 3/8-16 X 2″
7 111731 Screw, 5/16-18 X 1/2″, Tri
8 A0000646531 Handlebar, Lower
9 A0000648496 Cable, Blade Engage
10 G037561 Nut, Wing, 1/4-20, W/Ny Ins St Zn
11 A0001699594 Bolt, Carriage, 1/4-20 X 1.75″, GR5,
ZP
12 A0001446686 Wrench
13 A0001293143 Bolt, Shoulder, 1/4-20, 5/16″ X 1.75″
14 150491 Screw-8-32 X 1/2
15 333521 Bolt, Hex, Flange, 5/16-18 X 1.5″
16 A0001293103 Nut, Finish,-5/16-24, Left Hand, ZP
17 179231 Screw, SH, M6 25mm
18 A0000646612 Lever, Blade Engage
19 A0000646610 Bracket, Blade Engage
20 150361 Knob, PTO Clutch Cable
21 A0000646661 Adjuster, Traction Drive
22 A0000646546 Handlebar, Upper-Right
23 A0000646547 Handlebar, Upper-Left
24 217201 Maintenance Meter, W/66″ Wire
25 A0000648498 Lever, Traction Drive, Right
26 A0000648497 Guard, Hand
27 180691 Lever, Operator Presence, W/Wire
28 370511 Collar, Lever, 1″, Threaded
29 A0001293201 Spring, Torsion, Blade Engage Return
30 A0001293144 Bolt, Shoulder, 3/8-16, 1/2″ X 3/4″
31 A0000648499 Lever, Traction Drive, Left
32 A0002045838 Control Panel, Top Plate, w/labels
33 A0000967082 Control Panel, Front
Ref# Part# Description
34 164971 Guard, Switch
35 A0001231337 Grip, Vynafoam, 1″ID X 5.5″L
36 A0001231346 Switch, Plunger, NO/NC, Snap In
37 A0000646659 Link, Traction Control, Upper
38 139051 Cable, Throttle, 50″ (XD30)
A0000702424 Cable, Throttle, Honda (XD26)
39 222231 Switch, Snap-In, ES (XD30)
40 A0000702431 Wire Harness, ES (XD30)
A0002224499 Wire Harness, GXV390 (XD26)
41 112141 Cable Tie, 7-1/2″, L
42 10000040536 Hose, Vapor, 3/16″, ID (XD30)
43 265811 Clamp, Vapor Hose (XD30)
44 352831 Gas Tank Assembly, EPA/CARB
(XD30)
45 344431 Strap, Tank (XD30)
46 286971 Pad, Battery, 2.5″ X 6.125″ (XD30)
47 385301 Carbon Canister, 300cc, 1/4″ Tank
3/16″ Purge (XD30)
48 134471 Battery, 9 AH, 12V (XD30)
49 242301 Strap, Battery (XD30)
50 127971 Cable Tie, 17″, 50 GA (XD30)
51 A0000522190 Hose, Fuel, EPA/CARB Certified
(XD30)
52 A0000313387 Clamp, Fuel Line (XD30)
53 114681 Bolt, HCS, 1/4-20 X 1-1/4″, GR5, ZP
(XD30)
54 A0001645278 Label, Info, Control Panel
55 A0001645284 Label, Info, X-Drive
56 A0001645279 Label, Blade Engage
57 A0001645286 Label, Control Panel, Front
58 A0000627935 Bracket, Fuel Tank (XD30)
59 333331 Nut, Nylon Lock, Flanged, 3/8-16
(XD30)
60 333501 Bolt, Hex, Flange, 3/8-16 X 2″ (XD30)
