Draeger Interlock XT - Displayed Messages

User Manual • October 2004 Page 16
DRAEGER INTERLOCK
®
XT
DISPLAYED MESSAGES
Device is ready to accept a breath test. Blow into mouthpiece using
correct breath pattern.
Retest is required. Blow into mouthpiece using correct breath pattern.
Breath Test Passed. The vehicle can be started.
Device detected alcohol in the BAC sample. The vehicle will not start.
Wait for Handset to prompt "PLEASE BLOW", and then take the test again.
The time remaining when the vehicle can be started without another
breath test.
Vehicle has been started.
Device is preparing itself for the breath alcohol test. Wait for the
Interlock to display "PLEASE BLOW", and then take the test.
The breath sample was too short. Try the breath test again, but blow a
little longer.
The breath sample was too soft. Try the breath test again, but blow
harder.
The suck back was done incorrectly. Try the breath test again.
Remember the suck back is short, sharp and directly after the blow.
Device is temporarily locked out. Wait for the temporary lockout
countdown timer to nish. Turn ignition key to “ON” and try test again.
Device will "Lockout in XX day(s)". This message means that you are
past your original appointment date. Contact your service technician
immediately to make a service appointment.
Device has detected a need for a service. The vehicle cannot be started
until the Interlock is serviced. Contact your service technician.
Violations have been detected. Contact you service technician
immediately to make a service appointment.
Ready for Test
Please blow
Test Failed
Blow longer!
Repeat Test OK
Blow stronger!
Repeat Test OK
Suck after Blow!
Repeat Test OK
Retest required
Please blow
Test Passed
Free start time:
xx:xx
Drive Safely!
Warming Up
Please wait
Temporary Lockout
xx:xx:xx
Service Lockout
in xx days
Service Lockout
VIOLATION
RESET
