8
• After two seconds, "WAIT" appears on the
display.
• After six seconds, "READY" appears on
the display and a short acoustic signal
sounds. Simultaneously, the current test
number is displayed. The green lamp
flashes. The device is ready to start the
measurement.
Performing the Measurement
• The test subject must breathe evenly and continuously into the
mouthpiece. A continuous tone sounds and the green lamp flashes
when a sufficient breathing flow volume has been reached.
"Blow" appears on the display while the breath
sample is taken.
After delivering a sufficient breath sample, the
green lamp goes out and the continuous tone
falls silent.
"WAIT Analyzing" appears on the display.
Test Result
After 5 to 25 seconds (depending on the device
temperature and the measured concentration),
the measuring result appears on the display.
Errors during Breath Sample Delivery
If the breath sample volume is insufficient,
"Insufficient Volume" appears on the display.
A horn sounds briefly and the red lamp
flashes.
01233082_01_en.eps
WAIT
01333082_01_en.eps
READY
Test No. 00140
01433082_01_en.eps
Blow
01533082_01_en.eps
Analyzing
WAIT
‰
0.00
01633082_01_de.eps
01733082_01_en.eps
OK
Volume
Insufficient
