Technical Data
Technical Data
Ambient conditions -40° to +60°C (-40 to +140°F), 91.5 to 105.5kPA, 0-99% rel.hum
IP Rating IP 67, NEMA 4X (with O-rings fi tted)
Supply voltage Flame 1300
Flame 1700
Flame 2300
18 to 32VDC, current consumption 160mA quiescent state at 24 VDC ( maximum 230mA)
18 to 32VDC, current consumption 160mA quiescent state at 24 VDC ( maximum 180mA)
18 to 32VDC, current consumption 175mA quiescent state at 24 VDC ( maximum 240mA)
CE Marking Devices and protective systems for the use for the intended purpose in explosion-hazard area (Directive 94/9/EC), CENELEC only
Dimensions Approx: 275 x 155mm
Weight Aluminium Housing Less than 3.5kg (7.7lbs)
Stainless Steel Housing Less than 5kg (11lbs)
Regulatory Approvals ATEX Certifi cate Number: ITS 04 ATEX 11807
ATEX: II 2 G EEx d IIC
EEx d [ia] IIC T6 (T
amb
-50°C to +60°C)
EEx d [ia] IIC T5 (T
amb
-50°C to +70°C)
IECEx Certifi cate Number: ITS 04.0003
IEC Ex d: II 2 G EEx d IIC
EEx d [ia] IIC T6 (T
amb
-50°C to +60°C)
EEx d [ia] IIC T5 (T
amb
-50°C to +70°C)
FM/CSA Class I, Groups A, B, C, D
Class I, Zone 1, Groups IIA, IIB, & IIC
Ex d II C; T6/T5; -40°C ≤ T
amb
≤ +60°C / +70°C
Operating Distance 0.1m² (1 sq. foot) N-heptane fi re or Propane fl ame fi re at 18m and respond within 30 seconds. 5 inch (800W) propane fl ame at 1.44m
(4 feet 9 inches) and respond within 30 seconds.
Measuring Technique Characteristics
Torque Settings Housing Screws
Back Cover Locking screw
Front Cover Locking screw
15 Nm
0.8 Nm
0.8 Nm
Reliability - Mean time Between Failure (MTBF) ≥ 100,000 Hours
Response time to Fire Flame 1300
Flame 1700
Flame 2300
3.5 seconds
1 second
3.3 seconds

Dräger FD 10 Series Specifications
