STATUS M ESSAGES
VF8 DELTA/DELTA XL/KAPPA 20-9
etCO
2
Cal. Failed Calibration failed. • Retry calibration.
• Return the pod to hospital’s technical
personnel.
etCO
2
pod
Disconnected
The sidestream pod is unplugged
from the monitor.
• Check cable and connection.
• Replace the cable, if necessary.
etCO
2
pod
Incompatible
Corrupt EEPROM. The wrong
software or hardware version.
• Try a new pod.
• Consult the hospital’s technical
personnel.
Disconnect
Duplicate etCO
2
pods
Multiple pods are connected. Disconnect unwanted duplicate pod.
Service etCO
2
pod
Pod must be serviced if pump hrs. >=
20,000 hrs.
Contact DrägerService or replace pod.
CO2: H/W
Problem
Microstream pod hardware
malfunction.
Disconnect the Microstream pod, then
reconnect it. If the message persists
return the pod to the hospital’s
technical personnel.
Message Condition Suggested Action
