B-52 DELTA/DELTA XL/KAPPA VF8
B T
ECHNICAL DATA
CO2/Flow Adult/Pediatric 8mL 15 mm <11 g
Flow Performance
Adapter/Sensor Type Flow Range Flow Accuracy
Flow neonatal ±40 Greater of ±3 % reading or 0.125 L/min
Flow adult/pediatric ±180 Greater of ±3 % reading or 0.5 L/min
CO2/Flow neonatal ±25 Greater of ±3 % reading or 0.125 L/min
CO2/Flow pediatric ±120 Greater of ±3 % reading or 0.25 L/min
CO2/Flow adult/pediatric ±180 Greater of ±3 % reading or 0.5 L/min
Note: Static flow testing with standard, known temperature, gas composition and straight inlet
conditions
Pressure Performance
Adapter/Sensor Type
Airway
Pressure
Range
Pressure Accuracy
Flow neonatal or adult/pediatric ±120 cmH2O Greater of ±2 % or 0.5 cmH2O
CO2/Flow neonatal, pediatric or
adult/pediatric
±120 cmH2O Greater of ±2 % or 0.5 cmH2O
Note: Static testing with standard, known pressure condition
CO2 Performance
Adapter/sensor type/size CO2 Range CO2 Accuracy
Flow (all sizes) 0 to 40 ±2 mmHg
41 to 70 ±5 % of reading
71 to 99 ±8 % of reading
CO2/Flow (all sizes) 0 to 40 ±2 mmHg
41 to 70 ±5 % of reading
71 to 99 ±8 % of reading
NOTE: Accuracy obtained under specified test conditions
CO2 alarm limit resolution: 0.1 mmHg (0.01 kPa)
Quantitative effects of humidity and
condensate on accuracy
Full accuracy specifications are maintained for all non-
condensing humidity levels.
Adverse effects on performance of
cyclical pressures up to 10 kPa (100
cmH2O)
No effect on accuracy
Effect of barometric pressure on
accuracy
No effect on accuracy
Gas leakage: <1.6 ml/min
