Dräger Infinity Series Quick Reference Guide

Infinity Delta/Delta XL/Kappa - Quick Reference Guide
Intended for quick reference only.
Refer to Instruction For Use Manual.
INFINITY DELTA/DELTA XL/KAPPA - QUICK REFERENCE GUIDE | 21
© 2010 Draeger Medical, Inc.
NIBP Problems
NBP No Pulsation
MAP appears to be
incorrect
NBP </> alarm limit
NBP measurement
timeout
Possible Cause
Weak signal. Monitor
is unable to detect a
sufficient number of
pulsations of adequate
amplitude within two
minutes.
MAP calculated on
displayed SBP and
DBP.
Incorrect limits or
incorrect patient
category.
Measurement lasted
longer than 2 mins
(adult or peds) or
90 sec (neo).
Action
Check the patient and
treat if necessary.
Check the hose and
cuff. Check for proper
size, placement of
cuff.
No action required.
The monitor uses the
step deflation method.
The MAP is determined
first. The DBP and
SBP are calculated
from the MAP.
Check alarm limits
Check patient
category.
Move cuff to limb with
less movement. Ensure
proper cuff size. Adjust
inflation limit. Retry
measurement.

Dräger Infinity Series Specifications

General

Manufacturer	Dräger
Device Type	Patient Monitor
Weight	5 kg to 10 kg (depending on the model and configuration)
Connectivity	Ethernet, USB, WLAN (optional)
Parameters Monitored	ECG, SpO2, NIBP, Temperature, Respiration
Alarm System	Visual and audible alarms, customizable alarm limits
Device Category	Medical Device
Series	Infinity
Display	Color TFT
Display Size	12.1 inches
Power Supply	AC Power, Internal Battery
Battery Life	Up to 4 hours (depending on configuration)
