Dräger Infinity Series Quick Reference Guide

Infinity Delta/Delta XL/Kappa - Quick Reference Guide
Intended for quick reference only.
Refer to Instruction For Use Manual.
INFINITY DELTA/DELTA XL/KAPPA - QUICK REFERENCE GUIDE | 22
© 2010 Draeger Medical, Inc.
IBP Problems
Pressure waveform not
showing on monitor
Pressure waveform not
showing at ICS
Acquired blood
pressure is different
form estimated value
No IBP value appears
on screen
Possible Cause
Loose connection
Main screen parameter
priority incorrect.
Parameter not in one
of top two positions.
Air bubbles in pressure
circuit. An extra tubing
is attached to circuit.
Transducer is posi-
tioned incorrectly.
Pressure transducer
with different sensitivi-
ties is used. Other
causes.
Measurement is OUT
OF RANGE. Pressure
transducer cable is
damaged.
Action
Ensure that transducer
is properly connected.
Go to menu-main
screen and highlight
and shift parameter to
desired location using
trim knob.
Right click on upper
left of waveform box
opening manual lead
select; choose wave-
form to be displayed in
desired position.
Remove air bubbles.
Remove extra tubing.
Reposition pressure
transducer. Check
transducer. Re-zero
transducer.
Check the measuring
condition. Replace
cable or transducer.
