Dräger Isolette 8000 - Dr extachter Isolette Disassembly and Assembly; Disassembly Procedure Steps; Assembly Procedure Steps

PDF-9237 | 19.08-1 | AW | LE | Subject to modications | © 2019 Drägerwerk AG & Co. KGaA
Remove Gaskets
I n s t a l l G a s k e t s
3
21
Remove sleeves from ring
Install iris port sleeves
5
19
Remove sensor module
Install sensor module,
connect sensor module
cable to upper shell
6
18
Switch o device
Switch on device
1
23
Disconnect power plug
Reconnect power plug
2
22
Remove grommets
Install grommets
4
20
Slowly raise hood
Close hood
7
17
Remove mattress
Install mattress
8
16
Lift scale from bed
Install scale
9
15
Remove x-ray tray
Install x-ray tray
10
14
Remove bed
Install bed
11
13
Remove t-bars
I n s t a l l t - b a r s
12
12
Disassembly
Remove impeller cover
Install impeller cover
15
9
Let Device Cool
16
Remove reservoir
Install reservoir
14
10
Remove upper cover
Install upper cover
13
11
Careful: Collection bottle could contain patient uids
When the device has
cooled, remove heater
radiator
When the device
has cooled, install
heater radiator
16
7
If equipped, remove clamp
and pull the impeller from
the motor shaft
Install the impeller on the
motor shaft. If equipped,
install clamp
17
Remove the clamp from
thecondensation manage-
ment hose, discard
Install the clamp on
the condensation
management hose
19
5
Remove plug by
turning 90 °
Install plug by
turning 90 °
20
4
Slide the reservoir assembly
out from the front of the
incubator shell
Slide the reservoir assembly
in the front of the incubator
shell
21
3
Disassemble the reservoir
(pull latch at top, remove side
latches, remove cover)
Reassemble the reservoir
(push latch at top, latch side, install
cover)
22
7
Remove and replace the
Air Inlet Filter
Replace Air Inlet Filter &
install cover
23
1
2
Careful: The heater could
be hot enough to cause
burns. Avoid removing our
touching heater until de-
vice has been switched o
for at least 45 minutes
Careful: The water in the humidier chamber could be hot enough to
cause burns. Use caution when handling the reservoir.
Assembly
Reconnect the conden-
sation bottle to the conden-
sation management hose
6
Disconnect the condensa-
tion bottle from the conden-
sation management hose
18
8
