24 Instructions for use Oxylog 3000 plus SW 1.n
Symbols
Spn-CPAP Spontaneous Continuous Positive
Airway Pressure (spontaneous
breathing with continuous positive
pressure level)
SpO
2 Saturation of peripheral oxygen
Tapn Time before apnea is recognized
Te Expiratory time
Ti Inspiratory time
Tplat% Plateau time in % of inspiratory time
UN United Nations
VC-AC Volume-Controlled –
Assisted-Controlled ventilation
VC-CMV Volume Controlled - Controlled
Mandatory Ventilation
VC-SIMV Volume Controlled - Synchronized
Intermittent Mandatory Ventilation
VT Tidal volume
VTapn Tidal volume during apnea
ventilation
VTe Expiratory tidal volume
VTi Inspiratory tidal volume
Abbreviation Explanation
Symbol Explanation
Key for initiating a manual inspira-
tion or for extending the current
inspiratory time
Key for setting further ventilation
parameters
Key for setting and displaying alarm
limits
Insp.
Hold
Key for displaying measured values
Key for switching between the
pressure, flow or CO
2 (optional)
curves in small and large view
Key to silence the acoustic alarm
signal for 2 minutes
Key for acknowledging
alarm messages
Symbol Explanation
Values
Curves
Alarm
Reset
To Next Page
